Premium Window Film

Metalized Series

A premium mirror-like finish that will not interfere with GPS or wireless signals.

Manufactured in the United States by Erikson International, Las Vegas, NV. No nanoGard film is sourced from China.

Nano Ceramic Metalized Series

A product that delivers a high level of clarity and heat rejection. It provides a premium mirror-like finish to your vehicle’s windows, while making sure not to affect GPS or wireless signal performance.

Measured range

Visible light transmitted
3–70%
UV rejected
>99%
Infrared rejected
35–60%
Total solar energy rejected
44–60%
Thickness
2 MIL

Technical Data Sheet PDF

Hybrid Series

A nano ceramic and heavy metal hybrid providing the best heat rejection for sunny regions with long summers. High-performance at low cost.

Measured range

Visible light transmitted
3–35%
UV rejected
>99%
Infrared rejected
87–93%
Total solar energy rejected
80–95%
Thickness
2.5 MIL

Technical Data Sheet PDF

Nano Ceramic Infusion Classic Series

A harmonious trifecta of nano ceramic, metal, and carbon. This combination brings out the best of all worlds while simultaneously getting rid of their individual flaws.

Measured range

Visible light transmitted
33–78%
UV rejected
>99%
Infrared rejected
79–80%
Total solar energy rejected
54–73%
Thickness
2 MIL

Technical Data Sheet PDF

Nano Ceramic Infusion Series

A premium version of the Nano Ceramic Infusion Series with unsurpassed heat rejection technology. The number one choice among our ultra-luxury minded customers.

Measured range

Visible light transmitted
15–68%
UV rejected
>99%
Infrared rejected
85–93%
Total solar energy rejected
59–82%
Thickness
2 MIL

Technical Data Sheet PDF

Features

  • Heat Rejection

  • High Visibility

  • Chip Protection

  • Scratch Resistant

  • 99% UV Rejection

  • Limited Lifetime Warranty

Metalized Series, answered

Which film in the Metalized Series rejects the most heat?

The Hybrid Series, by a clear margin: 80% to 95% total solar energy rejected with 87% to 93% infrared rejection, against 44% to 60% TSER for the Nano Ceramic Metalized films. The Nano Ceramic Infusion Series sits between them at 59% to 82% TSER. The Hybrid films pair carbon with ceramic and are the ones the data sheet points at for sunny regions with long summers.

Do the metalized films block GPS or mobile networks?

The data sheets state plainly that the Hybrid Series and the Hybrid Low Reflective Series do not block GPS or mobile networks, and the Nano Ceramic Metalized Series is engineered to give a mirror-like finish without affecting GPS or wireless performance. That is the whole design brief for these films — the appearance of a metallised tint without the signal penalty metallised films are known for.

What is the Infusion Series?

A multi-layer construction combining nano ceramic, metal and carbon, at 2 MIL. The Infusion Classic grades measure 54% to 73% total solar energy rejected; the Infusion Series above it reaches 59% to 82% TSER with 85% to 93% infrared rejection. Its data sheet also claims a seasonal effect the others do not: it traps heat in winter and reflects it in summer.
